MSI B450M MORTAR MAX Socket AM4
Thông tin Sản Phẩm
MSI B450M MORTAR MAX Socket AM4
Military style with Extended heatsink design for better thermal solution, DDR4 Boost, Core Boost, Turbo M.2 and USB 3.2 Gen2 connector
- Supports 1st, 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics Desktop Processors for Socket AM4
- Supports DDR4 Memory, up to 4133(OC) MHz
- Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed.
- Lightning Fast Game experience: 1x TURBO M.2, AMD Turbo USB 3.2 GEN2, Store MI technology
- Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
- DDR4 Boost: Advanced technology to deliver pure data signals for the best gaming performance and stability
- MULTI-GPU: With PCI-E STEEL ARMOR slot. Supports 2-Way AMD Crossfire™
- Flash BIOS Button: Simply use a USB key to flash any BIOS within seconds, without installing a CPU, memory or graphics card.
MSI B450M MORTAR MAX
STRONGER THAN STEEL
MSI B450M MORTAR MAX SPECIFICATIONS
| SOCKET | AM4 |
| CPU (MAX SUPPORT) | RYZEN 9 |
| CHIPSET | AMD® B450 Chipset |
| DDR4 MEMORY | 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) For AMD Ryzen Gen3 (R5/R7/R9) 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) For AMD Other CPU 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE) |
| MEMORY CHANNEL | Dual |
| DIMM SLOTS | 4 |
| MAX MEMORY (GB) | 64 |
| PCI-E X16 | 2 |
| PCI-E X16 | Gen3(PCI_E1), Gen2(PCI_E4) |
| PCI-E X1 | 1 |
| SATAIII | 4 |
| M.2 SLOT | 2 |
| RAID | 0/1/10 |
| TPM (HEADER) | 1 |
| LAN | 1x Realtek® RTL8111H-CG |
| USB 3.2 PORTS (FRONT) | 2(Gen1, Type A) |
| USB 3.2 PORTS (REAR) | 1(Gen2, Type C), 1(Gen2, Type A), 4(Gen1, Type A) |
| USB 2.0 PORTS (FRONT) | 4 |
| USB 2.0 PORTS (REAR) | 2 |
| SERIAL PORTS(FRONT) | 1 |
| PARALLEL PORT(FRONT) | 1 |
| AUDIO PORTS (REAR) | Realtek® ALC892 Codec |
| DISPLAYPORT | 1 |
| HDMI | 1 |
| DIRECTX | 1 |
| FORM FACTOR | Micro ATX |
