Thông Số Kỹ Thuật :
Socket compatibility |
|
Height (without fan) | 165 mm |
Width (without fan) | 150 mm |
Depth (without fan) | 52 mm |
Weight (without fan) | 865 g |
Height (with fan) | 165 mm |
Width (with fan) | 150 mm |
Depth (with fan) | 78 mm |
Weight (with fan) | 1030 g |
Material | Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating |
Max. TDP | See CPU compatibility list |
Fan compatibility | 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25 |
Scope of delivery |
|
Warranty | 6 Years |
Thông Số Kỹ Thuật Quạt :
Model | Noctua NF-A15 PWM |
Bearing | SSO2 |
Max. rotational speed (+/- 10%) | 1500 RPM |
Max. rotational speed with L.N.A. (+/- 10%) | 1200 RPM |
Min. rotational speed (PWM, +/-20%) | 300 RPM |
Max. airflow | 140,2 m³/h |
Max. airflow with L.N.A. | 115,5 m³/h |
Max. acoustical noise | 24,6 dB(A) |
Max. acoustical noise with L.N.A. | 19,2 dB(A) |
Input power | 1,56 W |
Voltage range | 12 V |
MTTF | > 150.000 h |
