| GENERAL |
- Enclosure Type: Mid-tower
- Motherboard Compatibility: E-ATX (Up to 277 mm), ATX, Micro-ATX, Mini-ITX
- Rear-Connecting Motherboard Support (BTF, Project Zero): Yes (ATX, Micro-ATX)
- Materials: SGCC steel, clear tempered glass (white), tinted tempered glass (black)
|
| DIMENSIONS |
- Height (with feet): 506 mm (19.9 in)
- Width: 315 mm (12.4 in)
- Depth: 481 mm (18.9 in)
- Volume: 76.7 L
- Weight: 13.46 kg (27.47 lb)
|
| COMPATIBILITY & CLEARANCE |
- CPU Cooler Height: 165 mm
- GPU Length: Up to 459 mm (with <56 mm thickness fans installed at the front-right) Up to 410 mm (with 56 mm thick 420 mm AIO and fans installed at the front-right)
- PSU Length: 200 mm
- Top Radiator & Fan Thickness: Up to 80 mm (360 mm) Up to 62 mm (420 mm)
|
| FRONT I/O PORTS |
- USB 3.2 Type-A: 2
- USB 3.2 Gen 2×2 Type-C (20 Gbps): 1
- Headset Audio Jack: 1
|
| EXPANSION SLOTS |
|
| DRIVE BAYS |
|
| FAN SUPPORT |
- Front-Right: 3 x 120 mm / 3 x 140 mm (1 x F420 RGB Core included)
- Top: 3 x 120 mm / 3 x 140 mm
- Bottom: 3 x 120 mm / 3 x 140 mm (1 x F420 RGB Core included)
- Rear: 1 x 120 mm (1 x F120Q (CV) included)
|
| RADIATOR SUPPORT |
- Front-Right: Up to 420 mm
- Top: Up to 420 mm
- Bottom: Up to 360 mm
- Rear: Up to 120 mm
|
| FAN SPECS |
- Model: F420 RGB Core
- Speed: 2,000 ± 200 RPM
- Airflow: 98.61 CFM
- Static: 3.2 mmH2O
- Noise: 34.5 dBA
- Fan Connector: 8-pin
|
| FAN SPECS |
- Model: F120Q (CV)
- Speed: 1,350 ± 150 RPM
- Airflow: 60.2 CFM
- Static: 1.05 mmH2O
- Noise: 24.1 dBA
- Fan Connector: 3-pin
|
| CONTROL HUB SPECS |
- Fan Channels: 3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)
- RGB Channels: 4 x NZXT 8-pin / 1 x NZXT RGB
- Max LED Support: Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices.
- System Requirements: USB 2.0 Internal Header 8-pin PCIe Power
|
| GENERAL |
- Warranty: 2 years
- Model Number: CM-H92FW-P1 CM-H92FB-P1 CM-H92FW-P2 CM-H92FB-P2
- UPC: 810074847889 810074847896 815671019530 815671019547
- EAN: 5056547207674 5056547207681 5056547208886 5056547208893
|
