SAPPHIRE PULSE A620AM – Socket AM5
Thông tin Sản Phẩm
Chipset |
AMD® A620A |
CPU Support |
Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
Memory Support |
2x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 64GB(2x 32GB), up to 7600 MHz(OC) |
PCI-E Expansion Slots |
1x PCIe 4.0 x16, 1x PCIe 4.0 x4
|
Display Connector |
DisplayPort x1, HDMI x1 |
Audio |
Realtek® ALC897 HD Audio, 5.1 Channel |
Network |
Realtek® RTL8111K Gigabit Ethernet |
Front USB Headers |
1x USB 3.2 Gen1 (2 x Type-A), 1x USB 2.0 (2 x Type-A) |
Rear Ports |
1× HDMI ™, 1× DisplayPort, 1× PS/2 4× USB 2.0, 2× USB 3.2 Gen 1 Type-A 1× LAN (RJ45) 3× Audio Jacks |
Storage |
1x PCIe 5.0 M.2, 1x PCIe 4.0 M.2, 4x SATA |
Dimensions |
Micro-ATX, 244x244mm |
Debug LED |
DRAM: Yellow, CPU: Red, GPU: White, Boot: Green |
