| GPU Engine Specs |
| CUDA Cores |
16384 |
| Boost Clock (MHz) |
2580 |
| Base Clock(MHz) |
2235 |
| Thermal and Power Spec: |
| Minimum System Power Requirement (W) |
850 |
| Supplementary Power Connectors |
3x PCIe 8-pin cables (adapter in box) OR 450 W or greater PCIe Gen 5 cable |
| Memory Specs: |
| Memory Clock |
21Gbps |
| Standard Memory Config |
24GB |
| Memory Interface |
GDDR6X |
| Memory Interface Width |
384-bit |
| Memory Bandwidth (GB/sec) |
1008 |
| Feature Support: |
| Real-Time Ray Tracing |
Yes |
| Ray Tracing Cores |
3rd Generation |
| Tensor Cores |
4th Generation |
| NVIDIA Architecture |
Ada Lovelace |
| Microsoft DirectX |
12 Ultimate |
| NVIDIA DLSS |
3 |
| PCI Express Gen 4 |
Yes |
| NVIDIA GeForce Experience |
Yes |
| NVIDIA Ansel |
Yes |
| NVIDIA FreeStyle |
Yes |
| Bus Support |
PCI-E 4.0 X16 |
| NVIDIA ShadowPlay |
Yes |
| NVIDIA Highlights |
Yes |
| OS Certification |
Windows 11 / 10, Linux, FreeBSDx86 |
| NVIDIA G-SYNC™-Ready |
Yes |
| Lighting module |
Programmable RGB: Aura Sync, Mystic Light, Polychrome, RGB Fusion |
| Game Ready Drivers |
Yes |
| NVIDIA Studio Drivers |
Yes |
| NVIDIA GPU Boost™ |
Yes |
| Vulkan API |
Yes |
| OpenGL |
4.6 |
| HDMI 2.1 |
Yes |
| DisplayPort 1.4a |
Yes |
| NVIDIA Encoder |
2x 8th Generation |
| NVIDIA Decoder |
5th Generation |
| VR Ready |
Yes |
| Accessories: |
| Installation Guide |
Yes |
| Power Guide |
Yes |
| Graphics Card Dimensions: |
| Length |
334mm |
| Height |
148mm |
| Width |
63mm |
| Display Support: |
| Multi Monitor |
Yes |
| Maxmium Digital Resolution |
7680×4320 |
| HDCP |
2.3 |
| Standard Display Connectors |
HDMI 2.1, 3x DisplayPort 1.4a |
