Essentials | |
Product Collection | Intel® Pentium® Gold Processor Series |
Code Name | Products formerly Comet Lake |
Vertical Segment | Desktop |
Processor Number | G6405 |
Lithography | 14 nm |
Use Conditions | PC/Client/Tablet |
CPU Specifications | |
Total Cores | 2 |
Total Threads | 4 |
Performance-core Base Frequency | 4.10 GHz |
Cache | 4 MB Intel® Smart Cache |
Bus Speed | 8 GT/s |
Processor Base Power | 58 W |
Supplemental Information | |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 128 GB |
Memory Types | DDR4 2666 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 41.6 GB/s |
Processor Graphics | |
Processor Graphics | Intel® UHD Graphics 610 |
Graphics Base Frequency | 350 MHz |
Graphics Max Dynamic Frequency | 1.05 GHz |
Graphics Video Max Memory | 64 GB |
4K Support | Yes, at 60Hz |
Max Resolution (HDMI) | 4096 x 2160 @ 30Hz |
Max Resolution (DP) | 7680 x 4320 @ 60Hz |
Max Resolution (eDP – Integrated Flat Panel) | 5120 x 3200 @ 60Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
Multi-Format Codec Engines | 1 |
Intel® Quick Sync Video | Yes |
Intel® Clear Video HD Technology | Yes |
# of Displays Supported | 3 |
Device ID | 0x9BA8 |
Expansion Options | |
Scalability | 1S Only |
PCI Express Revision | 3.0 |
PCI Express Configurations ‡ | Up to 1×16+4 | 2×8+4 |
Max # of PCI Express Lanes | 16 |
Package Specifications | |
Sockets Supported | FCLGA1200 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2015C |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Advanced Technologies | |
Intel® Gaussian & Neural Accelerator | 3.0 |
Intel® Thread Director | No |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Optane™ Memory Supported ‡ | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 ‡ | No |
Intel® Turbo Boost Technology ‡ | No |
Intel® Hyper-Threading Technology ‡ | No |
Intel® Virtualization Technology (VT-x) ‡ | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
Intel® 64 ‡ | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Security & Reliability | |
Intel® Standard Manageability (ISM) | Yes |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit ‡ | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
Intel Pentium Gold G6405 – 2C/4T – 4MB Cache – Upto 4.10 GHz (Chính Hãng )
