KEY SPECS |
- Motherboard Support:E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
- Enclosure Type:Mid-Tower
- Case Material:SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)
|
DIMENSIONS |
- Height (with feet):465 mm / 18.31 in
- Width:225 mm / 8.86 in
- Depth:430 mm / 16.93 in
- Weight:7.28 kg / 16.04 lb
|
COMPATIBILITY & CLEARANCE |
- CPU Cooler Height:Up to 170 mm
- GPU Length:Up to 410 mm
- PSU Length:Up to 200 mm
- Cable Management:Up to 28.7 mm
- Top Radiator:Up to 240 mm (280 mm with low-profile memory)
- Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness:Up to 55 mm
|
FRONT I/O PORTS |
- USB 3.2 Type-A:1
- USB 3.2 Gen 2×2 Type-C (20 Gbps):1
- Headset Audio Jack:1
|
EXPANSION SLOTS |
|
DRIVE BAYS |
|
FAN SUPPORT |
- Front:3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included)
- Top:2 x 120 mm / 2 x 140 mm
- Bottom:2 x 120 mm
- Rear:1 x 120 mm (1 x F120Q Case Version included)
|
RADIATOR SUPPORT |
- Front:Up to 360 mm
- Top:Up to 240 mm (280mm with low-profile memory only)
|
FAN SPECS |
- Model:F360 RGB Core (Case Version)
- Speed:1,700 ± 200 RPM
- Airflow:50.1 CFM
- Static:1.27 mm-H₂O
- Noise:23.3 dBA
- Fan Connector:3-pin
|
FAN SPECS |
- Model:F120Q (Case Version)
- Speed:1,350 ± 150 RPM
- Airflow:60.2 CFM
- Static:1.05 mm-H₂O
- Noise:24.1 dBA
- Fan Connector:3-pin
|
GENERAL |
- Warranty:2 years
- Model Number:CC-H52FW-R1 (White)
- UPC:810074845922 (White)
- EAN:5056547205861 (White)
|
