Printing Technology | Print Method:Impact dot matrix Control Panel:4 switches and 5 LEDs Print Direction:Bi-direction with logic seeking Number of Pins in Head:24 pins Control Code:ESC/P2 and IBM PPDS emulation |
Print Speed | High Speed Draft:10cpi: 347 cps 12cpi: 416 cps Draft:10cpi: 260 cps Letter Quality:10cpi: 86 cps |
Reliability | MTBF:Approx. 10,000 POH (25% Duty) Printhead Life:Approx. 400 million strokes/wire Mean Print Volume Between Failure (MVBF):Approx. 20 million lines (Except print head) |
Print Characteristics | Character Sets:Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15 Bitmap Fonts:Epson Draft: 10, 12, 15 cpi; Epson Roman & San Serif: 10, 12, 15 cpi, Proportional; Epson Courier: 10, 12, 15 cpi; Epson Prestige: 10, 12 cpi; Epson Script, OCR-B, Orator & Orator-S: 10cpi; Epson Script C: Proportional Scalable Fonts:Epson Roman, Epson San Serif, Epson Roman T & Epson San Serif H: 10.5pt., 8pt. – 32pt. (every 2pt.) Barcode:EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
Paper Path | Manual Insertion:Rear in, Top out Push Tractor:Rear in, Top out |
Paper Media | Cut Sheet (Single Sheet):Length: 100 ~ 364 mm (3.9 ~ 14.3″) Width: 100 ~ 257 mm (3.9 ~ 10.1″) Thickness: 0.065 ~ 0.14 mm (0.0025 ~ 0.0055″) Cut Sheet (Multi-part Forms):Length: 100 ~ 364 mm (3.9 ~ 14.3″) Envelope (No.6):Length: 92 mm (3.6″), Width: 165 mm (6.5″), Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205″) (Total) Envelope (No.10):Length: 105 mm (4.1″), Width: 241 mm (9.5″), Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205″) (Total) Continuous Paper (Single Sheet):Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0″) Continuous Paper (Multi-part Forms):Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0″) Roll Paper:Width: 216 mm (8.5″), Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035″) |
General | Memory Buffer:128KB |
Supported OS and Applications | Supported OS:Windows 95 / 98 / 2000 / Me /XP / Vista / 7 / 8 / 8.1 / 10 Utility:Epson Status Monitor 3: Microsoft® Windows® 2000 / XP / 7 / 8 / 8.1 / 10 |
Dimensions and Weight | Dimensions (W x D x H):362 x 275 x 154 mm Weight:4.1kg |
Consumables | Ribbon Cartridge Black:Approx. 2.5 million characters (LQ 10cpi, 48 dots/character) – C13S015639 |
Options | Options:Fabric Ribbon Cartridge (Black) – S015634 |
Environmental Conditions (Operating) | Temperature:5 ~ 35°C Humidty:10 ~ 80 % RH |
Acoustic Noise | Acoustic Noise:Approx. 53 dB(A) (ISO 7779 pattern) |
Interface | Standard:Bi-directional parallel interface (IEEE-1284 nibble mode supported) USB 2.0 Full-Speed Serial |
