CABLE LENGTH
ATX Cable | 1x 600mm (m) |
EPS Cable | 2x 600mm (m) |
PCIE Cable | 4x 450mm, 550mm, 650mm (m) |
SATA Cable | 1x 450mm, 550mm, 650mm (m) 2x 550mm, 650mm, 750mm (m) |
Four-Pin Peripheral Cable | 2x 550mm, 650mm, 750mm (m) |
Floppy Adapter | 1x 100mm |
AC Power | 1x 1800mm (m) |
Modular Cable Type | Full |
CONNECTOR QUANTITY
24 Pin ATX | 1x |
EPS (CPU) | 2x 8pin (4+4) |
PCIE | 4x 8pin (6+2), 4x 6pin |
SATA | 9x |
Four-Pin Peripheral | 6x |
Floppy | 1x |
POWER SPECS
AC Input | 100 – 240 VAC, 10-5A, 50 – 60 Hz | ||||
Rail | +3.3V | +5V | +12V | +5Vsb | -12V |
Max Output | 25A | 25A | 61A | 3.0A | 0.8A |
61A | |||||
150W | 732W | 15W | 9.6W | ||
Total | 750W @ +50C |
ADDITIONAL DETAILS
Operating Temperature | 0° to 50° C |
Japanese Capacitors | Main PCB |
ECO Mode | No |
MTBF | 100,000 Hours |
Net Weight | 17 lbs |
Size | 85mm (H) x 0mm (W) x 164mm (L) |
Approvals | TUV, cUL, UL, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS |
Fan Size / Bearing | 120mm Double Ball Bearing |
