Noctua NL-LC1-36 – 360mm Liquid Cooler
Giá Tân Doanh: 7,990,000₫
- Tình trạng: Mới 100%
- Bảo hành: 36 tháng
- Xuất xứ: Chính hãng
- Thương hiệu: Noctua
- Giá bán đã bao gồm VAT.
Thông tin Sản Phẩm
Pump block specifications
|
Pump model |
Asetek Emma V2 |
|
Pump block height |
70 mm |
|
Motor type (phases) |
Three phase |
|
Impeller type |
Centrifugal (closed) |
|
Bearing |
Ceramic sleeve and shaft |
|
Rated voltage |
12 V |
|
Starting voltage |
9.5 V |
|
Max. operating voltage |
13.2 V |
|
Input power (max) |
6 W |
|
Input power (typical) |
2 W |
|
Input current (max) |
0.5 A |
|
Input current (typical) |
0.17 A |
|
Max. rotational speed (manual mode)
|
3400 rpm |
|
Max. rotational speed (balanced mode)
|
2600 rpm
|
|
Max. rotational speed (quiet mode)
|
2100 rpm
|
|
Rotational speed @ 20% PWM
|
750 rpm |
|
Rotational speed @ 0% PWM
|
750 rpm |
|
Max. acoustical noise (manual mode) |
14.9 dB(A) |
|
Max. acoustical noise (balanced mode) |
7.8 dB(A) |
|
Max. acoustical noise (quiet mode) |
<5 dB(A) |
|
Cable length |
500 mm |
|
Connector type |
4-pin PWM |
|
Pin configuration |
|
|
Pin 1 |
Black: Ground (GND) |
|
Pin 2 |
Black: Voltage (Vcc) |
|
Pin 3 |
Black: RPM Signal |
|
Pin 4 |
Black: PWM Signal |
|
Cold plate material |
Copper CU1100 (99.95% high-purity) |
|
Cold plate size |
55.5 x 55.5 mm |
|
Construction |
Skived fin micro channels |
|
Mounting system |
SecuFirm2+ |
|
Mounting hole pitch |
78 mm |
|
Pump noise absorber |
NL-PNA1 |
|
Auxiliary cooling fan |
Optional (NL-ACF1) |
Coolant specifications
|
Composition |
|
|
Inhibitors |
|
|
Compatibility |
|
Tube specifications
|
Material |
EPDM (braided) |
|
Tube length |
410 mm |
|
Outer diameter |
12.5 mm |
|
Inner diameter |
7 mm |
|
Min. bend radius |
26 mm |
Radiator specifications
|
Form factor |
360 mm |
|
Material (fins) |
Aluminium |
|
Material (tubes) |
Aluminium |
|
Material (frame) |
Steel |
|
Fins per inch (FPI) |
20
|
|
Radiator size |
399.5 x 120 x 30 mm |
|
Fan configuration |
3x 120x120x25 mm |
|
Total radiator assembly thickness |
59
|
|
Screw threads |
UNC 6-32 |
Logistical specifications
|
Packaging dimensions
|
472 x 224.5 x 145 mm |
|
Packaging weight (including product) |
3060 g |
|
EAN |
9010018000559 |
|
UPC |
841501100550 |
|
Packaging unit |
4 pcs |
|
Packaging unit dimensions |
499 x 471 x 333 mm |
|
Packaging unit weight |
13.4 kg |
|
Unit weight (without packaging) |
1979 g |
